WEG SSW-07 User Manual

CHAPTER 2 - GENERAL INFORMATION
10
English
EX SSW07 0017 T 5 S _ _ _ _ _ _ Z
Market BR = Brazil EX = Export
WEG Soft- Starter Series SSW-07
SSW-07 Nominal Current 0017 = 17 A 0024 = 24 A 0030 = 30 A 0045 = 45 A 0061 = 61 A 0085 = 85 A 0130 = 130 A 0171 = 171 A 0200 = 200 A 0255 = 255 A 0312 = 312 A 0365 = 365 A 0412 = 412 A
Three- Phase Power Supply
220-575 Vac Optional:
S = Standard O = with Optional
Degree of Protection Blank = Standard IP=IP20
(1)
Special Hardware Blank = Standard H1 = Electronics supply:110to 130 Vac
(2)
H2 = Electronics supply:208to 240 Vac
(2)
Special Software Blank = Standard S1 = Special Software
End of Code
HOW TO SPECIFY THE SSW-07 MODEL:
NOTE! Theoptioneld(SorO)denesiftheSoft-StarterSSW-07willbeastandardversionorifitwillincludeanyoptional.Ifstandard,the
code ends here. AlwaysputtheletterZattheend.Forexample: EXSSW070017T5SZ = Standard Soft-Starter SSW-07 with 17 A and 220 V to 575 V to three-phase input with the User’s Guide in English, Spanish and Portuguese. Ifthereisanyoptional,theeldsmustbelledoutinthecorrectsequenceuntilthecodeiscompletedwiththeletterZ. Thestandardproductasdenedbythiscodeisdescribedas: DegreeofProtection:IP20from17Ato85AandIP00from130Ato412A.
(1) Only for models 130 A to 412 A. (2) Only for the 255 A to 412 A models.
