WEG SSW-07 User Manual

7
English
GENERAL INFORMATION
This manual presents the Soft-Starter installation, how to start it up,
its main technical characteristics and how to identify and correct the
most common problems. The manuals listed next must be consulted
in order to get more information regarding the functions, accessories
andworkingconditions:
Programming Manual, with a detailed description of the
parameters and its functions;
RS232 / RS485 Communication Manual.
DeviceNet Communication Manual.
These manuals are supplied in electronic format on the CD-ROM
that accompanies the Soft-Starter, or can be obtained at WEG’s
website:http://www.weg.net.
The Soft-Starter SSW-07 is a high performance product that permits
the start control of the three phase AC induction motors. Thus, it
prevents mechanical shocks on the load and current peaks in the
supply line.
para Ajustes
Tampa para
Trifásica
Opcionais Plug-In
Ajustes e Habilitar as
Proteções
DIP Swith para
Trimpots
Ajustes da
LED's para Indicação
DIP Switch para
Entrada de Alimentação
Reset (DI2 e DI3)
de Status da SSW-07
Classe Termica
Alimentação da Eletrônica
(A1 e A2)
Comanda Aciona/Desaciona
Motor (DI1) e
Saída para Motor
Saida a Relé
(13,14/23 e 24)
Three-phase
Power Supply
DIP Switch for
Soft-Starter adjustment
and protection enabling
Status Indication LEDs
of the SSW-07
Lid for optional Plug-in
Modules
Relay Output
(13, 14/23 and 24)
Motor Output
Electronic Power Supply
(A1 and A2)/
Start/Stop Command
of the Motor (D1) and
Reset (DI2 and DI3)
DIP switch to adjust
the Thermal Class
Trimpots to adjust
Figure 2.1 - Frontal view of the SSW-07
2.1 ABOUT THIS
MANUAL
2.2 ABOUT THE
SOFT-STARTER
SSW-07
CHAPTER 2
