50
English
CHAPTER 8
TECHNICAL CHARACTERISTICS
This chapter describes the electric and mechanical technical
characteristics of the Soft-Starter SSW-07 line.
SSW-07
Model
Motor voltage
220/230 V
Motor voltage
380/400 V
Motor voltage
440/460 V
Motor voltage
575 V
(Hp) (kW) (Hp) (kW) (Hp) (kW) (Hp) (kW)
17 A 5 3.7 7.5 5.5 10 7.5 15 11
24 A 7.5 5.5 10 7.5 15 11 20 15
30 A 10 7.5 15 11 20 15 25 18.5
45 A 15 11 25 18.5 30 22 40 30
61 A 20 15 30 22 40 30 50 37
85 A 30 22 50 37 60 45 75 55
130 A 50 37 75 55 100 75 125 90
171 A 60 45 100 75 125 90 150 110
200 A 75 55 100 75 150 110 200 150
255 A 100 75 150 110 200 150 250 185
312 A 125 90 175 130 250 185 300 225
365 A 150 110 200 150 300 225 350 260
412 A 150 110 250 185 350 260 450 330
Table 8.1 - Powers and currents according to UL508
SSW-07
Model
Motor
voltage
220/230 V
Motor
voltage
380/400 V
Motor
voltage
440/460 V
Motor
voltage
525 V
Motor
voltage
575 V
(Hp) (kW) (Hp) (kW) (Hp) (kW) (Hp) (kW) (Hp) (kW)
17 A 6 4.5 10 7.5 12.5 9.2 15 11 15 11
24 A 7.5 5.5 15 11 15 11 20 15 20 15
30 A 10 7.5 20 15 20 15 25 18.5 30 22
45 A 15 11 30 22 30 22 40 30 40 30
61 A 20 15 40 30 50 37 50 37 60 45
85 A 30 22 60 40 60 45 75 55 75 55
130 A 50 37 75 55 100 75 125 90 125 90
171 A 60 45 125 90 125 90 150 110 175 132
200 A 75 55 125 90 150 110 200 150 200 150
255 A 100 75 175 132 200 150 250 185 250 185
312 A 125 90 200 150 250 185 300 220 300 225
365 A 150 110 250 185 300 225 350 260 400 300
412 A 150 110 300 220 350 260 440 315 450 330
Table 8.2 - Powers and currents for WEG motors
NOTE!
The maximum powers indicated in table 8.1 are based on 3 x nominal
current of Soft-Starter SSW-07 during 30 s and 10 starts per hour
(3xIn @ 30 s).
8.1 NOMINAL POWERS AND CURRENTS ACCORDING TO UL508
8.2 NOMINAL POWERS AND CURRENTS FOR STANDARD IP55, IV POLE WEG
MOTOR
