WEICHAI WP12 User Manual

15
4.3.3 Checking the oil level
Make sure the boat is on oat or kept on a level surface. A dipstick is provided on
the crank case near to the oil lter assembly (gure 4.8). Check the oil level using
the oil dipstick. Safe oil level range is marked on the dipstick bottom (gure 4.9).
If the oil level is in between the high level and low level area, then the oil is at the
proper level for engine operation. (gure 4.10)
If necessary, top up the oil through the oil lling port. Do not overll.
DIPSTICK
Figure 4.8
Oil dipstick
H
H
H
OK
L
L
L
OK
OK
Figure 4.9 Figure 4.10
Immediately clean up any oil spillage to avoid personal injury
4.3.4 After an extended storage
If an engine is non-operational for an extended period of time (shing off season for
example) may accumulate water in the oil pan and internal surfaces of the engine
through normal condensation of high humid air. Water mixed lube oil cannot provide
adequate bearing protection at engine startup and operation. For this reason, the
company recommends replacing the engine oil with lters after extended storage.
The lubricating oil lm on the rotating parts and bearings of an engine (which has
been in storage for six months or more), may be insufcient when the engine is
started for the rst time
CAUTION

WEICHAI WP12 Specifications

General

Engine Model	WP12
Number of Cylinders	6
Displacement	11.596 L
Bore x Stroke	126 mm x 155 mm
Compression Ratio	17:1
Max Torque	2100N.m
Weight	1100 kg
Fuel System	High Pressure Common Rail
Fuel Consumption	≤195g/kWh
