31
5.7.4 Replacement of oil lter
Use the lter wrench to loosen the lter and remove it by hand refer gure 5.2 & 5.3.
Use a suitable tray under the lter location to collect oil spillage before removing
the lter.
Figure 5.2 Figure 5.3
Let the oil drain completely from the lter housing refer gure 5.4. Wipe the sealing
surface with a clean cloth, and apply fresh oil to the seal ring, then position the
lter on the housing by hand and tighten it with the help of lter wrench refer gure
5.5& 5.6
Figure 5.4 Figure 5.5
Figure 5.6
