2.3 OVERALL DIMENSIONS OF WP12 MARINE DIESEL ENGINE
(all dimensions are in mm)
Outsi de diamete
r
se a water outle
t
Figure 2.1
hea t exchanger
sea water outlet
air-cooler
sea water inlet
fuel oil filter
fuel oil pump
Figure 2.2
