WEICHAI WP12 User Manual

6
2.4 ENGINE MODEL IDENTIFICATION
WD
12
C xxx xx
Engine Speed X100 (RPM)
Rated Power (HP)
Application Code
Total Displacement Volume (Ltrs)
Water cooled Diesel Engine
2.5 ENGINE MODEL AND POWER RANGE
SR.NO Engine Model
Power Rating Rated Speed
HP KW RPM
1 WP12C350-15 350 258 1500
2 WP12C400-18 400 295 1800
3 WP12C450-21 450 330 2100
Table 2.3

WEICHAI WP12 Specifications

General

Engine Model	WP12
Number of Cylinders	6
Displacement	11.596 L
Bore x Stroke	126 mm x 155 mm
Compression Ratio	17:1
Max Torque	2100N.m
Weight	1100 kg
Fuel System	High Pressure Common Rail
Fuel Consumption	≤195g/kWh
