13
4.3.1 Cooling system
Capacity: 40 Liters
1. Make sure the main drain valve of the fresh water cooling system (above the oil
lter mounting) is closed properly. Refer gure 4.1
Figure 4.1
2. The coolant can be lled from the heat exchanger. Remove the cap provided
on the top (gure 4.2) and slowly ll the cooling system with recommended
coolant (gure 4.3). Slowly lling the coolant will help the air to escape without
trapping in the system.
For more details about coolant specication, refer section VI.
Figure 4.2 Figure 4.3
