weinor Opal Design II LED - Page 26

Instructions for Assembly
Item number 116523-0000
We reserve the right to make technical
changes
Version 4 01.04.2014 Page 26/49
Opal Design II / Opal Design II LED
A rafter assembly with mounting plate is recommended. The bracket position is
dependent on the cross sections and dimensions of the awning.
Cassette width
Rafter spacing
