weinor Opal Design II LED User Manual

Instructions for Assembly
Item number 116523-0000
We reserve the right to make technical
changes
Version 4 01.04.2014 Page 36/49
Opal Design II / Opal Design II LED
7.5 Conventional Opal Design II LED Volant Plus
Damage to the awning
Improper connection and wiring can damage the awning.
 Always retract the Volant Plus fabric completely before you retract the entire awning.
The use of any controls that do not ensure that the Volant Plus is retracted before the
entire awning is retracted is not permissible.
Figure 12: Circuit diagram - Conventional Opal Design II LED Volant Plus
