weinor Opal Design II LED User Manual

Instructions for Assembly
Item number 116523-0000
We reserve the right to make technical
changes
Version 4 01.04.2014 Page 38/49
Opal Design II / Opal Design II LED
7.8 Transformer box
7.8.1 Exploded drawing
Fig. 15: Transformer box
1 Transformer box cover 7 Ring terminal M8
2 Sheet metal holder for transformer 8 Washer DIN 9021-4.3-A2125B-21-A2
3 Blind rivet DIN 7337-A4 x 12 9 Toothed lock washer DIN 6797 A5,3
4 Transformer holder, inside 10 Socket head cap screw DIN912-M4x20
5 Housing floor profile 11 Socket head cap screw DIN912-M4x8
6 Ring terminal M5
Use the supplied breakout cable to adjust or operate the motor without a WeiTronic radio
receiver.
