Electronic Control Card TS004E
Technical data
Termi-
nal
Function Level Remark 32-pin mul-
tipoint con-
nector
8 General error - Output 24 V/100 mA 9A/B
9 Start permissible - Output 24 V/100 mA 8B
10 Table in Pos./
processing released
- Output 24 V/100 mA
Output 24 V/100 mA
8A
C Motor contactor forward - Output 24 V/2 A 5A/B
D Holding brake - - 6A/B
E Motor contactor reverse - - 14A/B
F Sensor Log. 1 active Input 24 V 15B
G Release brake Log. 1 active Input 24 V 15A
H Start state-controlled Log. 1 active Input 24 V 17B
T Temperature sensor Log. 0 active Input 24 V 17A
4.3 Climatic environmental conditions operation
Characteristic Unit Value
Ambient temperature °C 0 ... +40
Relative humidity, non-condensing % +5 ... +95
4.4 Climatic environmental conditions transportation and storage
Characteristic Unit Value
Ambient temperature °C -25 ... +55
Relative humidity, non-condensing % +5 ... +95
