Electronic Control Card TS004E
Mounting
6 Mounting
6.1 Mounting versions
Terminal PCB
Terminal PCB individually
Card holder
The card holder is provided for DIN rail mounting or screw mounting. The card
holder has screw terminals on the left and right hand sides for the connection of
the 24 V cables and the signal cables.
Housings
All housings have a terminal PCB already mounted.
Front panel mounting
Without door
Front panel mounting
With door
Screw mounting
Without door
Screw mounting
With door
DIN rail mounting
Without door
DIN rail mounting
With door
14 / 29
User manual_082018_1.0_en
