WEISS TS004E User Manual

Electronic Control Card TS004E
Technical data
4 Technical data
4.1 Technical data "Control Cad"
Characteristic Unit Value
Operating voltage V 24 (± 10%)
Current input mA Typ. 40 (without 24 V holding brake)
Input power holding brake A
DC
1.0 ... 2.0 (depends on type)
Digital inputs V Level LOW: 0 ... 5
HIGH: 15 ... 30
Input current: 6 mA
Digital outputs mA Output current: 100
(outputs: 4, 6, 7, 8, 9, 10)
Output current: 2000
(outputs: C, D, E)
Electromagnetic compatibility
Harmonized standard as per European directive
2014/30/EU:
Harmonic current emissions
Immunity
Emissions
-
EN 61000-3
EN 61000-4
EN 55014-1
Dimensions mm Eurocard: 100 x 160
4.2 Technical data "Terminal PCB"
Termi-
nal
Function Level Remark 32-pin mul-
tipoint con-
nector
+ +24 V - Supply voltage 3/4/A/B
- GND (OV) - Supply voltage 1/2/A/B
1 Direction of rotation LOW CW
HIGH CCW
Input 24 V 26A
2 Enable
(RESET/STOP)
LOW: -Disable
-Reset Alarm
HIGH: Enable
Input 24 V 19A
3 Start edge Rising edge Input 24 V 18A
4 Automatic - Output 24 V/100 mA 16B
5 Additional stop Log. 1 active Input 24 V 18B
6 position overrun - Output 24 V/100 mA 10B
7 Motor overload
(movement timeout)
- Output 24 V/100 mA 10A
User manual_082018_1.0_en
9 / 29
