Errors
10 Errors
10.1 Troubleshooting and error messages
Troubleshooting
In the case of an error, the red LED lights solid in the button STOP/RESET. The outputs 6, 7, 8 signal
the error.
The error message can be reset with the button STOP/RESET or with a LOW signal at terminal 2.
Error message
Issue Output 6 Output 7 Output 8 Description
Position
overrun
HIGH LOW HIGH The rotary indexing table/rotary indexing ring
overtravels the limit position.
Causes:
■
Stop delay time too long
■
Holding brake is worn → Adjust the
holding brake→ see mounting instructions
TD0003A..., TD0070A..., TD0026A..., see
chapter 1.4
Motor over-
load
(movement
timeout)
LOW HIGH HIGH Position cam on output flange does not
reach the inductive sensor within 10 sec-
onds (timeout).
■
Output flange with mechanical friction
■
Emergency Stop contactors have
disconnected motor cables
■
Emergency Stop contactors with contact
issues
■
Star/delta bridge in motor not correct
■
Holding brake not fully opened (verify
correct 24 V supply)
■
No signal from sensor (terminal F)
Short circuit LOW LOW HIGH
■
Overload at 24 V outputs (output current >
100 mA / > 2 A)
■
Signal voltage peaks of > 30 V
■
Supply voltage > 30 V
Overtempera-
ture
LOW LOW HIGH
■
Motor too hot
■
Temperature switch triggers
