33
WAS.handling Windows – Program
Group general (continuation):
stop input: Wiring Stop – Input: HIGH or LOW active
Unlike Quickstop, the axes remain enabled.
Waittime Enable: Switch-on delay for ENABLE signal.
Group drive:
Acopos Type: This shows the drive type.
switch frequency:
Modulation frequency of output stage
phase monitor Monitors, whether all 3 power phases are available to the drive. If only one phase is
connected, deactivate this monitoring.
Group find motor phase:
method: Method for determining the commutation angle.
Parameter must only be changed by WEISS service technician.
current: Power used for inphasing.
Group motor:
motor type: The motor type is pre-set and must not be changed.
temp sensor: Here you can select the type of motor temperature sensor.
motor torque: Display of the maximum motor torque.
Part 5:
Part 5 displays the current position, speed and motor current.
