WEISS WAS.handling - Test Menu

35 WAS.handling Windows – Program
4.4 Test menu
The Test menu contains functions for setting up and checking the axes.
4.4.1 Manual mode
The upper part of the dialog displays the current positions of the connected axes. Below is a tab to operate all
axes together or each axis separately.
All axes:
Step mode for each
axis
Reference drive for all
axes
Set current position as
machine zero point
Activation / deactivation
of axes (software
enable)
Speed override
Current position
