Welbilt MERRYCHEF conneX User Manual

3 Technical data
Back to contents >
Merrychef conneX
®
service and repair manual 25
Electrical connected load ratings – X12 Standard power version
Electrical supply
1N~ 220-230V 50Hz
1N~ 220-230V
50Hz
1N~ 220V 60Hz
2~ 208V 60Hz
Connections used
L + N + E
L + N + E
L + N + E
2P + E
Arrangement
Single phase
Single phase
Single phase
Two pole
Max power input
[W]
2990
3680
2990
4500
Rated current per phase
[A]
13
16
13
20
Power output
Rated power output convected
heat
[W]
2200
2200
2200
2200
Rated power output
microwave (IEC 705) 100%
[W] 1000 1000 1000 1000
Rated power output
combination mode (convected
heat + microwave)
[W] 900 + 1000 1300 + 1000 900 + 1000 1300 + 1000
Electrical connected load ratings – X16 High power version
Electrical supply
1N~ 220-230V 50Hz
2N~ 380-400V 50Hz
1N~ 220V 60Hz
2~ 200V 50/60Hz
Connections used
L + N + E
L1 + L2 + N + E
L + N + E
2P + E
Arrangement
Single phase
Twin phase
Single phase
Two pole
Max power input
[W]
6000
2500 + 3300
6000
6000
Rated current per phase
[A]
32
16 / 32
32
32
Power output
Rated power output convected
heat
[W] 3200 3200 3200 3200
Rated power output microwave
(IEC 705) 100%
[W]
2000
2000
2000
2000
Rated power output
combination mode
[W] 3200 + 2000 3200 + 2000 3200 + 2000 3200 + 2000
Regulatory standards compliance
Degree of protection
IPX3
Noise emission
max. 65 [dBA]
Approval marks
Tested safety
UKCA, CE, CB (IEC), UL
Hygiene
UL-EPH (NSF/ANSI 4)
