Merrychef conneX
®
service and repair manual 24
3 Technical data
3.1 Technical data charts
Dimensions and weights
Width
conneX12 including packaging
520
[mm]
20.5
[in]
conneX16 including packaging
620
[mm]
24.4
[in]
Appliance (X12) without packaging
356
[mm]
14
[in]
Appliance (X16) without packaging
459
[mm]
18.1
[in]
Height
conneX12 including packaging
855
[mm]
33.7
[in]
conneX16 including packaging
855
[mm]
33.7
[in]
Appliance (X12) without packaging
619
[mm]
24.4
[in]
Appliance (X16) without packaging
619
[mm]
24.4
[in]
Depth
conneX12 including packaging
820
[mm]
32.3
[in]
conneX16 including packaging
820
[mm]
32.3
[in]
Appliance (X12) without packaging, door closed
641
[mm]
25.2
[in]
Appliance (X16) without packaging, door closed
683
[mm]
26.9
[in]
Weight
conneX12 high power version, including packaging
68.7
[kg]
151
[lbs]
conneX16 high power version, including packaging
79.2
[kg]
175
[lbs]
conneX12 high power version, excluding packaging
58.7
[kg]
130
[lbs]
conneX16 high power version, excluding packaging
67.2
[kg]
148
[lbs]
conneX12 standard power version, including packaging
60.0
[kg]
133
[lbs]
conneX12 standard power version, excluding packaging
50.0
[kg]
111
[lbs]
Safety clearances
Right / Left
0
[mm]
0
[in]
Top / Rear (for ventilation)
50
[mm]
2
[in]
Electrical connected load ratings – X12 High power version
Electrical supply
1N~ 220-230V 50Hz
2N~ 380-400V 50Hz
1N~ 220V 60Hz
2~ 200V 50/60Hz
Connections used
L + N + E
L1 + L2 + N + E
L + N + E
2P + E
Arrangement
Single phase
Twin phase
Single phase
Two pole
Max power input
[W]
6000
2500 + 3300
6000
6000
Rated current per phase
[A]
32
16 / 32
32
32
Power output
Rated power output convected
heat
[W]
2200
2200
2200
2000
Rated power output microwave
(IEC 705) 100%
[W]
2000
2000
2000
2000
Rated power output
combination mode
[W] 2200 + 2000 2200 + 2000 2200 + 2000 2200 + 2000
