Technical data
18 Operating Manual MXPC 303 Z/603 T
3.3 General Connections
Type of connection
Version
Use for
Pneumatic
Inlet (suction)
Output (pressure side)
Hose nozzle DN 8-10
Hose nozzle GL 18
Hose ID = 8-10 mm
Hose ID = 8-10 mm
Accompanying parts (optional)
Inlet (suction)
Hose nozzle DN 8-10
Compression fitting DN 10
Hose ID = 8-10 mm
Tube 10/8 mm (AD/ID)
Equipment
Cooler input/output
Hose nozzle GL 14
Hose ID = 8 mm
Mains connection
IEC 60320 C14
IEC 60320 C13
3.4 Materials
ATTENTION
The operator must ensure that the application with the installed materials is not
critical
Beware of the safety/warning instructions (see chapter
2.4.1 Hazardous substances)!
Components in contact with media
Components
Material
Pumping unit
 Pump heads
 Diaphragm
 Valves
 Seals
 PTFE
 PTFE coating on elastomer
 PEEK
 EPDM
Pneumatic connections
 Vacuum hoses
 Screw fittings
 O-ring seals
 PTFE
 PVDF
 EPDM
Attachment parts
 Separator/emission condenser
 Connector for hose
 Connection block incl. hose fitting
 Glass (shatter proof)
 PTFE
 PVDF
