Description
Operating Manual MXPC 303 Z/603 T 19
4 Description
4.1 Scope of application
General description
 The device is suitable for conveying neutral gaseous media.
 The device is suitable for use in laboratories and industry when working in rough vacuum
conditions.
 Gases enter the device, they are compressed, and finally expelled via the vacuum
diaphragm pump.
 The glassware separates condensate media.
 The device must be connected in accordance with the legal requirements and operated in
compliance with the technical data.
4.2 Structure
The device consists of a vertically mounted vacuum diaphragm pump (pump for short) and
glassware.
The vacuum diaphragm pump consists of a pumping unit with two or four pump heads, a drive
with a 1-phase electric motor and mechanical elements.
4.2.1 Device display
Fig. 4-1. 117047: view front (left) and back (right)
Fig. 4-2. 117057: view front
NOTE Display with accompanying material at the inlet (see chapter 3.3 General Connections).
