CMP201D User Guide
CM2-MOD-02 > Basic Setting
CM2-MOD-02 Basic Setting is where users input the parameters for IP Input, Modulation Output and
IP Output.
IP Input-Parameter Setting> On this page, there are three tabs where you can modify the multicast
IP, port and parameter of IP Input. There are Port 1, Port 2, and Batch Setting. The input can
accept Multicast or Unicast and support MPTS and SPTS.
Port 1 and Port 2 have same interface. It shows the 512 channels. Check the box under Enable to
enable a channel. Input the correct Multicast/Unicast IP address and IP port, and select the correct
Protocol for the source IP. Once done, click Apply for the changes to take effect. See the image
below for reference.
