CMP201D User Guide
92

Repeat the operations to add next TS (frequency) until NIT streams of all the frequencies
have been included. Finally click Apply button to let all configuration take effect. Then
searching programs in your STB, you will get all programs in the order of LCN which you set.
5.3.5CM2-ISDBT-R01/R01A
CM2-ISDBT-R01/R01A module supports up to 4/8 adjacent frequencies modulating with 1 RF female
connector for output.
CM2-ISDBT-R01>Basic Setting
Click the Apply button on the right side to make the change take effect.
Name
Range
Name
Range
Bandwidth(MHZ)
6M
RF level
25~45dBmV/85~105dBμV
Frequency (KHz)
48000~862000
FFT Mode
2K
