CMP201D User Guide
90

Repeat the operations to add next TS (frequency) until NIT streams of all the frequencies
have been included. Finally click Apply button to let all configuration take effect. Then
searching programs in your STB, you will get all programs in the order of LCN which you set.
5.3.4 CM2-OFDM-R01/R01A
CM2-OFDM-R01 / R01A module supports up to 4/8 adjacent frequencies modulating with 1 RF
female connector for output.
Module configuration is similar to IP Setting.
CM2-OFDM-R01>Basic Setting
Click the Apply button on the right side to make the change take effect.
Name
Range
Name
Range
Bandwidth
6M, 7M, 8M
RF level
0-31.5dBmv/60-91.5dBμv
Frequency (KHz)
48000~862000
