Wellav CMP201D - CR2-DVBT2-00 Module; CR2-DVBT2-00 Basic Settings

CMP201D User Guide
39
Channel
standard
CH
Off-Air
CH2-57MHz, CH3-63MHz, CH4-69MHz~
CH67-791MHz, CH68-797MHz, CH69-803MHz
STD
CH2-57MHz, CH3-63MHz, CH4-69MHz~
CH133-849MHz,CH134-855MHz, CH135-861MHz
IRC
CH2-57MHz, CH3-63MHz, CH4-69MHz~
CH133-849MHz,CH134-855MHz, CH135-861MHz
HRC
CH2-55.75MHz, CH3-61.75MHz, CH4-67.75MHz~
CH133-847.75MHz,CH134-853.75MHz, CH135-859.75MHz
Status, Service Configuration and System is similar to CR2-DVBC-00.
5.1.5 CR2-DVBT2-00
CR2-DVBT2-00 is a 4-channel DVB-T/T2 receiving and descrambling module with 1 RF connectors
and 2 CI slots.
Module configuration is similar to CR2-DVBC-00.
CR2-DVBT2-00 >Basic Setting
