CMP201D User Guide
112
5.4 Function modules
5.4.1 CP2-EAS-00
CP2-EAS-00 module provides the ability to interrupt Encoder playback and switch to an external
transport stream. This feature is for the US market and requires the CMP201D chassis to be set for
ATSC standard. A common application of Emergency Alert Systems is for Broadcast and Audio
Muting.
The trigger switched video content on the Encoders can be sensed using a DC contact closure or the
SCTE-18 EAS standard over ASI/IP when the EAS is “Paved” or actively replacing the encoder
outputs.
