Wellav CMP201D - CR2-DVBS2 FTA-01 Status; CR2-DVBS2 FTA-01 Parameter Setting

CMP201D User Guide
31
Click TS Analysis of each channel, you can see TS bit rate analysis. Click Reset Counter to reset
the Continuity Count Error counter. In Search bar, you can input key words or numbers, such as
PIDs, Type or service, for a quickly search.
Click the icon to check service information of all the inputs.
You can check program details by clicking the program item.
CR2-DVS2FTA-01 > Parameter Setting
Channel 1.1, 1.2,1.3 and 1.4, 4 LNBs are powered independently.
Name
Range
Satellite Frequency (MHz)
950~14500
Symbol Rate(KBaud)
1000~45000
LNB Frequency(MHz)
0~13550
LNB Power
Off/13v/18v
LNB 22KHz
Off/22KHz
