CMP201D User Guide
CM2-MOD-02 > Status
The Status page contains status information of IP Input, Modulation Output and IP Output.
IP Input > CM2-MOD-02 has 1024 IP input channels. Those channels are divided into two RJ45
ports, each port has 512 IP input channels. Click Port 1 tab, users can obtain the 256 channels
status information such as input source IP address and port number, total bitrate (Mbps) and
effective bitrate (Mbps). The TS analysis and Service List button on each channel allow users to
check the detailed information in each TS. See the image below for reference.
512 channels in port 1
