i12 Manual Page 31 - Revision: 6-13-2023
7. Allow the system to fill. This should take roughly 30 minutes. Water will fill the hot tank
first, then the cold, and then the ambient tank will be the last to fill.
8. The i12 WILL NOT dispense cold water until the water has become chilled to a set
temperature. This may take up to 45min (from the water being turned on) to reach
temperature, at which time cold will become selectable as a dispense option. Once the cold
water is chilled, the ice process will begin, and the first batch of ice should be heard falling
within an hour of turning the water on.
9. After an hour, dispense hot and cold water and ice. Ensure all functions operate properly.
AMBIENT TANK
COLD TANK
ICE BIN
HOT TANK
