White Magic PRO 1900 - Page 17

2003 Chevy
Fuel Line Kit Installation Procedure
07-01-03
5.) Loosen or remove
this clamp to allow for
more working room.
6.) Using a good quality
mini pipe cutter (such as
“Rigid”), cut into the
metal return line as
shown. (Fig. 3)
***NEVER, UNDER
ANY CIRCUM-
STANCES, USE ANY
ELECTRICAL DEVICE
OR OTHER DEVICE
THAT MAY CAUSE A
SPARK TO CUT THE
FUEL LINE, OR TO
PERFORM ANY TASK
IN THE VECINITY OF
ANY MOTOR FUEL.***
Approx. 1”
Fig. 3
Approx. 1”
Fig. 4
Gas Flow
**The return line is the
5/16” diameter tube con-
nected to one of the two
flexible lines.
(Fig. 4)
***The 3/8” line is the
main feed from the fuel
pump. DO NOT
cut this
line. (Fig. 4)
Be sure to measure hose
diameter prior to each
installation.
14
