WHYTE Service Manual
Item Description
1
Dropout Spacer (8mm wide) Left Side, for SRAM Maxle 148mm (Gunmetal Col-
our)
2 M5 x 16mm long Countersunk Head Screw
3 M4 x 12mm long Countersunk Head Screw
4 Rear Derailleur Hanger, for SRAM Maxle 148mm (Black Colour)
5 M4 x 8 long Grub Screw.
6 Axle Nut, for SRAM Maxle 142mm (Black Colour)
Figure 12: Whyte Dropout Assembly,
For SRAM Maxle 148mm
18
