WinGD WARTSILA RT-flex58T-E - Page 82

Maintenance0803−1/A1
RT-flex58T-E
Winterthur Gas & Diesel Ltd.
2/ 2
Longitudinal Section:
2303−1
1132−1
1132−2
1203−1
2138−1
2722−1
2751−1 to 2751−4
3140−1
9223−1
3303−1 to 3303−4
3403−1 to 3403−4
2124−1 to 2124−3
3103−1
3130−1
3130−2
2708−1 to 2708−3
3425−1
1224−1
8752−1
4103−1
to 4103−3
WCH00994
Engine Cross Section and Longitudinal Section
2013 / V2
