Marine Installation Manual 2022-03 6-15
6 Engine Dynamics
6.3 Longitudinal vibration (pitching)
X62DF-S2.0
For the assembly of friction type stays, please see the latest version of the
WinGD Assembly Instructions for WinGD friction type stays (DG 9715),
which is provided on the WinGD webpage under the following link:
Assembly instruction - Friction type stays
The layout of friction type stays are as shown in the drawing ‘Engine stays’ in the
MIDS (DG 9715).
Hydraulic type stays
Hydraulic type stays can be installed on either the engine’s free end or driving
end side according to third-party suppliers.
