Connecting the machine
39
Connecting the mains cable
Requirements for the mains cable:
 Cable of type H07 RN-F or equivalent
 Cross-section and number of wires appropriate for voltage, fusing and total connected load
 Follow the connection diagram.
The connection diagram is attached to the rear of the partition wall for the electrical installation
compartment.
 Connect the wires of the mains cable according to the connection diagram.
 Place new bridges in accordance with the connection diagram. Firmly press the bridges with a
screwdriver.
 Set the interlock (P545) as part of menu-guided commissioning.
Example
