Rinse aid and detergent
24
8.2 Rinse aid
Rinse aid is necessary to ensure that water on the items being washed drains off after washing as a thin film.
This ensures that the wash items dry quickly.
Rinse aid is automatically dispensed using a dosing device.
8.3 Detergent
Caution
 Do not use acidic detergents.
 Do not use any foaming products (e.g. manual washing-up liquid) for treating the items being
washed, as these will build up in the machine.
A detergent is necessary to ensure that the leftovers and dirt on the wash items are cleaned.
Detergents can be dosed as follows:
 Manually as detergent powder
 Automatically as liquid detergent
INFO The detergent dosing device is not included in the scope of delivery of all machines.
8.3.1 Manual dosing detergent powder
IMPORTANT Only deposit detergent powder when the machine is ready for operation.
 After each dosing (pre- and post-dosing), start the wash cycle immediately to mix the detergent powder
with the water.
 Adhere to the dosing instructions on the packaging of the detergent.
UC-S
UC-M/-L/-XL
Tank capacity
9.5 l
15.3 l
Pre-dosage
≙ Dosing of 3 g/l
30 g
45 g
Rinse water volume per wash cycle
2.0 l
2.2 l
Post-dosing every 5 wash cycles
30 g
33 g
8.3.2 Refilling the detergent or rinse aid
A lack of chemicals is promptly detected and indicated on the display:
Lack of detergent
Lack of rinse aid
 Refill chemicals in the next 20 seconds so that the wash result is not affected.
IMPORTANT If the chemicals are not refilled in time, the dosing device will be deactivated. Air also gets
into the dosing hose and the dosing device must be primed  6.3.2).
Variant A
Variant B
External containers and suction tubes
Integral storage tank
