WITTUR Hydra PLUS - Bottom Fixings for Car Sills - Centre Parting Car

CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
1.15.1
Subject to change without notice! Soggetto a modifica senza preavviso!
BOTTOM FIXINGS FOR CAR SILLS - CENTRE PARTING CAR DOORSIxxxxxxxxxxxx
FISSAGGI INFERIORI SOGLIE CABINA - PORTE CABINA AD APERTURA CENTRALE
PL C C 1
500 ÷ 750 250
800 ÷ 1050 400
1100 ÷ 1400 550
1450 542
/
1500 552
1550 562
1600 409 409
1650 416 416
1700 423 423
1750 430 430
1800 483 483
PL C C 1 C 2
600 ÷ 900 250
950 ÷ 1150 400 /
1200 ÷ 1750 550 /
1800 ÷ 2350 500 500
2400 ÷ 2800 486 486
2850 428 428 428
2900 463 463 463
2950 469 469 469
3000 474 474 474
3050 480 480 480
3100 486 486 486
3150 491 491 491
3200 497 497 497
PL C
900 ÷ 1000 250
1050 ÷ 1350 400
1400 ÷ 1450 550
PASSAGGIO LIBERO
PL = CLEAR OPENING
PASSAGGIO LIBERO
FORI PER VITI M10
FIXING HOLES M10
FILO PAVIMENTO
FINISHED FLOOR LEVEL
Typ 02/C
Typ 62/C - 66/R
Typ 42/C
(PL=1200 ÷3200)
Typ 44/R
(PL= 600 ÷1150)
Typ 62/C
(PL=1500 ÷3200)
Typ 66/R
C C C
C1C1
C2 C2
C C C
C1 C1
C C C C
CC1 C1
PL C C 1
1200 490
1250 506
1300 524
1350 540
1400 334
1450 344
1500 354
1550 364
1600 390
1650 400
1700 410 /
1750 420
1800 440
1850 450
1900 460
1950 470
2000 480
2050 490
2100 500
2150 510
2200 520
PL C C 1
2250 530
2300 410
2350 417
2400 424
2450 431
2500 439
2550 446 /
2600 453
2650 460
2700 486
2750 493
2800 500
2850 394
2900 400 400
2950 406 406
3000 411 411
3050 417 417
3100 422 422
3150 428 428
3200 433 433
PL = CLEAR OPENING
PASSAGGIO LIBERO
PL = CLEAR OPENING
