CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
5.2.t
Subject to change without notice! Soggetto a modifica senza preavviso!
ATTENTION: GM > GW
ATTENZIONE: GM
> GW
*
FOUR PANELS CENTRAL OPENING CAR DOOR, TYPE 42/C PL=1200÷3200
PORTA DI CABINA 4 ANTE OPPOSTE, TIPO 42/C PL=1200÷3200
FOR GLASS DOORS AND GLASS-FRAMED DOORS
ALWAYS USE REINFORCED OPERATORS
PER PORTE CON ANTE IN VETRO E VETRATE
CONSIDERARE SEMPRE OPERATORI RINFORZATI
SEMI-REINFORCED OPERATORS
STANDARD OPERATORS OPERATORI SEMI-RINFORZATI
OPERATORI STANDARD REINFORCED OPERATORS
OPERATORI RINFORZATI
P
C C1 C2 D D1 D2 D3 D4 D5 D6 M1 GW WS
GM P GM=P
1200 1850 1800
1900
1900
1250 1925 1875 1900 1950
1300
1424 225 62 442 / / 820
2000 1950
2000
2000
1350 2075 2025 2000 2050
1400 2150 2100
2100
2100
1450 2225 2175 2150
1500
550 /
/
2300 2250
2370
2370
1550 2375 2325 2420
1600 2450 2400 2420 2370 2470
1650 2525 2475 2470 2520
1700
974 163 610
2600 2550 2520 2570
1750 2675 2625 2570 2570 2620
1800 2750 2700 2750 2800
1850 2825 2775 2800 2850
1900 2900 2850 2850 2900
1950 2975 2925 2900 2750 2950
2000 / 3050 3000 2950 3000
2050 3125 3075 3000 3050
2100
500 500
3200 3150 3050 3100
2150
1850
3275 3225 3100 3150
2200 3350 3300 3150 3100 3200
2250 3425 3375 3200 3250
2300 3500 3450 3300
2350 / / / 225 3575 3525 3350
2400 3650 3600 3650
2450 3725 3675 3700
2500 3800 3750 3750
2550 / 500 800 3875 3825 3800
2600 486 486 3950 3900 3850
2650 4025 3975 3900
2700 4100 4050
/
3950
2750 4175 4125 4000
2800 2350 4250 4200 4050
2850 428 428 428 4325 4275 4100
2900 463 463 463 4400 4350 4420
2950 469 469 469 4475 4425 4470
3000 474 474 474 4550 4500 4520
3050 480 480 480 4625 4575 4570
3100 486 486 486 4700 4650 4620
3150 491 491 491 4775 4725 4670
3200 497 497 497 4850 4800 4720
*
*
*
A
C
B
PL (1) (2)
1200 125 211
1250 126 214
1300 127 217
1350 129 221
1400 131 226
1450 133 230
1500 140 239
1550 141 242
1600 142 245
1650 143 248
1700 144 251
1750 145 254
1800 169 280
1850 171 284
1900 174 290
1950 176 294
2000 185 295
2050 187 299
2100 188 302
2150 189 305
2200 190 305
2250 191 311
2300 192 315
2350 193 318
2400 215 342
2450 216 345
2500 217 348
2550 241 351
2600 242 353
2650 243 356
2700 244 358
2750 246 362
2800 247 365
2850 287 407
2900 291 413
2950 293 417
3000 306 421
3050 308 424
3100 311 429
3150 313 433
3200 315 437
CAR DOOR TOTAL WEIGHT
PESO TOTALE PORTA DI CABINA
kg
LH=2000
WEIGHTS FOR DOORS WITH STANDARD AND DOUBLE SKIN PANELS
PESI PER PORTE CON ANTE STANDARD E TAMBURATE
WEIGHTS FOR DOORS WITH GLASS AND GLASS-FRAMED PANELS
PESI PER PORTE CON ANTE IN VETRO E VETRATE
(2)
(1)
