CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
6.2.t
Subject to change without notice! Soggetto a modifica senza preavviso!
SIX PANELS CENTRAL OPENING CAR DOOR, TYPE 62/C PL=1500÷3200
PORTE DI CABINA 6 ANTE OPPOSTE, TIPO 62/C PL=1500÷3200
SEMI-REINFORCED OPERATORS
OPERATORI SEMI-RINFORZATI
REINFORCED OPERATORS
OPERATORI RINFORZATI
C C1 D D1 D2 M1 GW WS
GM P
165 354 2050 2000 2095 2095
167 364 2116 2050 2145 2145
172 390 2183 2130 2215 2195
174 400 2250 2200 2265 2245
176 410 974 163 / 610 2316 2250 2315 2295
178 420 2383 2330 2345 2345
182 440 2450 2400 2445 2445
185 450 2516 2450 2495 2495
187 460 2583 2530 2545 2545
189 470 2650 2600 2615 2595
190 480 2716 2650 2665 2645
193 490 2783 2730 2715 2695
194 500 2850 2800 2745 2745
196 510 1850 2916 2850 2795 2795
198 520 / 2983 2930 2845 2845
200 530 3050 3000 2895 2895
210 410 3116 3050 3135 3115
212 417 3183 3130 3165 3165
214 424 3250 3200 3235 3215
215 431 3316 3250 3285 3265
217 439 3383 3330 3335 3315
219 446 / 500 800 3450 3400 3365 3365
221 453 3516 3450 3415 3415
224 460 3583 3530 3465 3465
323 489 3650 3600 3645 3645
234 493 3716 3650 3715 3695
235 500 2350 3783 3730 3765 3745
257 394 3850 3800 3815 3795
260 400 400 3916 3850 3845 3845
262 406 406 3983 3930 3895 3895
279 411 411 4050 4000 3945 3945
280 417 417 4116 4050 3995 3995
283 422 422 4183 4130 4045 4045
285 428 428 4250 4200 4115 4095
286 433 433 4316 4250 4165 4145
*
*
*
*
*
PL
1500
1550
1600
1650
1700
1750
1800
1850
1900
1950
2000
2050
2100
2150
2200
2250
2300
2350
2400
2450
2500
2550
2600
2650
2700
2750
2800
2850
2900
2950
3000
3050
3100
3150
3200
B
C
PL (1) (2)
1500 165 281
1550 167 285
1600 172 293
1650 174 297
1700 176 301
1750 178 305
1800 182 311
1850 185 316
1900 187 320
1950 189 324
2000 190 327
2050 193 332
2100 194 336
2150 196 340
2200 198 344
2250 200 348
2300 210 360
2350 212 365
2400 214 369
2450 215 372
2500 217 376
2550 219 380
2600 221 384
2650 224 389
2700 233 400
2750 234 403
2800 235 406
2850 257 431
2900 260 436
2950 262 440
3000 279 444
3050 280 447
3100 283 452
3150 285 456
3200 286 459
CAR DOOR TOTAL WEIGHT
PESO TOTALE PORTA DI CABINA
kg
LH=2000
WEIGHTS FOR DOORS WITH STANDARD AND DOUBLE SKIN PANELS
PESI PER PORTE CON ANTE STANDARD E TAMBURATE
WEIGHTS FOR DOORS WITH GLASS AND GLASS-FRAMED PANELS
PESI PER PORTE CON ANTE IN VETRO E VETRATE
(2)
(1)
FOR GLASS DOORS AND GLASS-FRAMED DOORS
ALWAYS USE REINFORCED OPERATORS
PER PORTE CON ANTE IN VETRO E VETRATE
CONSIDERARE SEMPRE OPERATORI RINFORZATI
ATTENTION: GM > GW
ATTENZIONE: GM
> GW
*
