WITTUR Hydra PLUS - Page 61

CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
7.1.t
Subject to change without notice! Soggetto a modifica senza preavviso!
PESO TOTALE STANDARD OPERATORS REINFORCED OPERATORS
TOTAL WEIGHT OPERATORI STANDARD OPERATORI RiNFORZATI
LH=2000
C D D1 D2 GW WS GM
PP
74 1250 1200 1215
81
250
912 217 / 1350 1300 1265 1250
87 378 1450 1400 1315
92 1550 1500 /
94
400
1137
225
1650 1600
1550
1594
97 1750 1700 1600
102
475
1850 1800 1810
111 1950 1900 1860 1854 1904
117
550
2050 2000 1910 1954
133 483 2150 2100 2110 2154
135 495
/
2250 2200 2160 2154 2204
140 508
1300 287
2350 2300 2210 2254
146 446 2450 2400 2410 2454
148 456 2550 2500 2460 2454 2504
150 466 2650 2600 2510 2554
153 476 2750 2700 2560 2604
155 486 2850 2800 2610
2604
2654
ONE PANEL CAR DOOR, TYPE 72/R-L PL=600÷1400XXI
PORTA DI CABINA 1 ANTA, TIPO 72/R-L PL=600÷1400
PL
600
650
700
750
800
850
900
950
1000
1050
110 0
1150
1200
1250
1300
1350
1400
FOR GLASS DOORS AND GLASS-FRAMED DOORS
ALWAYS USE REINFORCED OPERATORS
PER PORTE CON ANTE IN VETRO E VETRATE
CONSIDERARE SEMPRE OPERATORI RINFORZATI
PL (1) (2)
600 74 109
650 81 113
700 87 121
750 92 125
800 94 128
850 97 133
900 102 140
950 111 148
1000 117 156
1050 133 173
1100 135 178
1150 140 182
1200 146 189
1250 148 193
1300 150 197
1350 153 202
1400 155 205
WEIGHTS FOR DOORS WITH STANDARD AND DOUBLE SKIN PANELS
PESI PER PORTE CON ANTE STANDARD E TAMBURATE
WEIGHTS FOR DOORS WITH GLASS AND GLASS-FRAMED PANELS
PESI PER PORTE CON ANTE IN VETRO E VETRATE
(2)
(1)
CAR DOOR TOTAL WEIGHT
PESO TOTALE PORTA DI CABINA
kg
LH=2000
AC
