WITTUR Hydra PLUS - Page 69

CABLE CHAIN ASSEMBLY FOR CENTRAL OPENING DOORS TYP. 42/C - 62/C
MONTAGGIO GUIDACAVI PER PORTE AD APERTURA CENTRALE TIPI 42/C - 62/C
CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
OVERALL WITH OPEN DOOR
INGOMBRO CON PORTA APERTA
M2
OVERALL WITH OPEN DOOR
INGOMBRO CON PORTA APERTA
M2
OVERALL WITH CLOSED DOOR
INGOMBRO CON PORTA CHIUSA
M1
OVERALL WITH CLOSED DOOR
INGOMBRO CON PORTA CHIUSA
M1
Typ 42/C
PL M1 M2
1200 619 929
1250
639
962
1300 974
1350
664
1012
1400 1024
1450
689
1062
1500 1074
1550
714
1112
1600 1124
1650
739
1162
1700 1174
1750
764
1212
1800 1224
1850
789
1262
1900 1274
1950
814
1312
2000 1324
2050
839
1362
2100 1374
2150
864
1412
2200 1424
2250
889
1462
2300 1474
2350
914
1512
2400 1524
2450
939
1562
2500 1574
2550
964
1612
2600 1624
2650
1004
1677
2700 1689
2750
1029
1727
2800 1739
2850
1039
1762
2900 1774
2950
1064
1812
3000 1824
3050
1089
1862
3100 1874
3150
1114
1912
3200 1924
Typ 62/C
PL M1 M2
1500 689 1074
1550
714
1112
1600 1124
1650
739
1162
1700 1174
1750
764
1212
1800 1224
1850
789
1262
1900 1274
1950
814
1312
2000 1324
2050
839
1362
2100 1374
2150
864
1412
2200 1424
2250
889
1462
2300 1474
2350
914
1512
2400 1524
2450
939
1562
2500 1574
2550
964
1612
2600 1624
2650
1004
1677
2700 1689
2750
1029
1727
2800 1739
2850
1039
1762
2900 1774
2950
1064
1812
3000 1824
3050
1089
1862
3100 1874
3150
1114
1912
3200 1924
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
8.3.2
Subject to change without notice! Soggetto a modifica senza preavviso!
