WITTUR Hydra PLUS - Page 72

STRONG FRONT FIXINGXXXXXXI
FISSAGGIO FRONTALE PESANTE
CAR DOOR HYDRA PLUS
PORTE DI CABINA HYDRA PLUS
16.10.2015
Code/Codice
Version/Versione
TC.2.001981.EN
/
Code/Codice
Version/Versione
Date/Data
Page/Pagina
3201.30.0600V01
A
24.11.2010
8.5.1
Subject to change without notice! Soggetto a modifica senza preavviso!
DOOR TYPE
ABC PL
TIPO PORTA
PL/4
200 / 600 ÷ 1450 02/C
200 600 1500 ÷ 1800 02/C
PL/8 200 / 600 ÷ 1150 44/R
PL/12 200 / 900 ÷ 1450 66/R
A
B
C
B
A
C
PL
A
A
B
C
PL
A
400
B
C
D
PL
DOOR TYPE
ABC PL
TIPO PORTA
750 / 1200 ÷ 1800 42/C
1000 / 1850 ÷ 2200 42/C
PL/8 1300 / 2250 ÷ 2650 42/C
1500 / 2700 ÷ 2900 42/C
1000 2400 2950 ÷ 3200 42/C
750 / 1500 ÷ 1800 62/C
1000 / 1850 ÷ 2200 62/C
PL/12 1300 / 2250 ÷ 2650 62/C
1500 / 2700 ÷ 2900 62/C
1000 2400 2950 ÷ 3200 62/C
DOOR TYPE
ABCD PL
TIPO PORTA
PL/4
/ / 60 600 ÷ 1350 12/R-L
500 / 60 1400 ÷ 1800 12/R-L
/ / 60 600 ÷ 1350 32/R-L
PL/6 500 / 60 1400 ÷ 1850 32/R-L
500 500 60 1900 ÷ 2100 32/R-L
PL/6
/ / 60 600 ÷ 1350 35/R-L
500 / 60 1400 35/R-L
PL/2
/ / 100 600 ÷ 1350 72/R-L
500 / 100 1400 72/R-L
M8
M8
M8
185
185
185
