11) * Full Charged (V) (only for DEFAULT battery type)
Select “11. Full Charged (V)” and press “OK”. Press “up” or “down” to change the 1
st
digit, press “ok” to switch to
next digit. Input the value of Full Charged Voltage per battery specification. Press “OK”.
12) Save
Select “12. Save” and press “OK” to complete setting battery parameters.
2. Clear Energy Data
Select “2. Clear Energy” and press “OK”, “input password” is shown. Input the password “0001”, press “Up” or
“Down” to change the 1
st
digit, press “OK” to switch to next digit, when “0001” is shown on the screen, press “OK”. If
“Incorrect, Try Again!” is shown on the screen, press “Back” and input the password again.
3. Clear Events
Select “3. Clear Events”, press “OK” button twice to clear all the events.
4. Country (refer to Set country)
Select “4. Country”, press “OK”, current country setting is shown, input new country code & press “OK”
5. Anti Reflux
5.Anti Reflux Control
1.Anti Reflux Control
Enable
Disable
2.Reflux Power
***KW
The user can enable “Anti Reflux Control” to limit the max export power to grid.
Select “2. Reflux Power” to input desired max export power to grid.
6. IV Curve Scan
6.IV Curve Scan
1.Scan Control
Enable
Disable
2.Scan Period
***min
3.Force Scan
The user can enable “IV Curve Scan” (MPPT scan) to make WKS I inverter to find the global max power point
periodically to deliver max power from a partially shaded PV array.
The user can input scan period or make WKS I inverter to perform a scan right away.
“Up”
↑
“Down”↓
“Up” ↑
“Down”↓
