Legend
1 Cup storage
2 On/Off -switch
3Function keys
4 All-in-one spout
5 Cover for mains plug
6Water tank
7 Drip tray with drip tray grid
8 Coffee grounds container
9 Hot water spout
10 Beverage buttons
11 Disp lay
12 Bean container lid
13 Lid for ground coffee insert
14 Brewing unit lid
15 Brewing unit
Leave this page folded out while reading the user manual.
This will give you an overview of the complete coffee machine, including all its components.
The positions
1 15
...
are dealt with again in the individual chapters.
