Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 790.4mm
Height 597mm
Depth 523mm
(591mm with opened cup storage)
Coffee bean hopper approx.550g each(external: approx. 1,400g)
(1
Weight empty approx. 75kg
Water supply TW15 (DN 15at least DN 6or 1/4") hose connector
with main water supply and contaminant filter, with
amesh size of 0.08mm, by customers on-site.
(2
At least 0.05MPa (0.5bar) supply pressure at
2l/min (low pressure). At least 0.30MPa (3.0bar)
supply pressure at 2l/min (default). Maximum
0.6MPa(6bar). Maximum inlet temperature 35°C.
The set of hoses provided with the new coffee
machine and/or the new water filter must be used.
Do not use the old set of hoses.
Water quality For drinking water with carbonate hardness from
5°dKH or higher, aWMFwater filter must be fitted.
Water drain tube Hose aminimum of DN 19, minimum downward
slope of 2cm/m
Use at elevation above
sea level
< 2,000m
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
These specifications (IEC60335–2-75) for the water connection to the coffee
machine apply in EU member states. It may be necessary to also observe
additional country-specific regulations. Outside the EU countries acceptance of
the standards quoted is to be checked by the legal entity or natural person who
wishes to use the coffee machine.
