Wood-mizer LX25 User Manual

Setup
Remove and inspect the parts boxes
3
3-2 LX25 8/25/21 Setup
014151
Pin, 3/8x2 1/4 SQ Wire Lock
1 X200-1082
Clamp Assy, Log Metric
(F05022-25 incl in bag kit)
1
X100-348
Bracket, Scale
1 046627
Handle, 33/64 ID x 1-1/4 OD x
4 PLASTIC (Sub 1)
1
X100-984
Block, Plastic Scale Timbery
2 F05011-123
Washer, 12mm Split Lock
(Sub 1)
1
F05010-212
Nut, M12x1.75 Free Zinc
1 F05027-19
Nut, M12-1.75 Zinc Jam
1
TABLE 1: PARTS BOX CONTENTS
Part # Description Part # Description Qty
