MAINTENANCE
Drive Belt Tension Adjustment
4
4-4 doc021023 MAINTENANCE
Loosen four motor mounting bolts (A). Use adjustment bolt B to adjust belt tension.
FIG. 4-2
MP200_008
MP200EH6S_MANUAL
A(4)
B
