Wood-mizer MP200 E6S - Dimensions and Model Specifications

PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
Specyfikacje EGdoc021023 5-2
5
See table 5-1. The overall dimensions and weight of MP200 are given in the table below.
5.2 Specifications of the planer/moulder
See table 5-2. Wood-Mizer planer/moulder nomenclature is given in the table below.
See table 5-3. See the table below for specifications of the ECO planer/moulder motors for European
markets.
Planer/moulder type MP200
Weight 370 kg
Weight with transport box 443 kg
Height 1314 mm
Width 931 mm
Length 1258 mm
Length with optional table 2465 mm
TABLE 5-1
Volts
MP200EA6S 1 ph 230V CE
MP200EA6U 1 ph 230V UL
MP200EB6S 3 ph 230V CE
MP200EB6U 3 ph 230V UL
MP200EC6U 3 ph 460V UL
MP200EH6S 3 ph 400V CE
TABLE 5-2
MP200EH6S
Top cutter motor
specifications
Side cutter motor
specifications
Feed motor specifi-
cations
Motor Type Electric Motor Electric Motor Electric Motor
Rated Voltage 3x400V 3x400V 3x400V
Rated revolutions 2860 r.p.m. 2860 r.p.m. 1400 r.p.m.
Rated power 6kW 6kW 0,18 kW
Wood-Mizer Part No. 537386 537385 532802
Wood-Mizer Reducer Part
No.
---- --- 533637
TABLE 5-3
