SETUP & OPERATION
Variable speed motor manual
3
3-9 EGdoc021023
WARNING! To sharpen dull knife, the flat side of the knife can be
grinded. The pair of knives must have the same profile. Always grind
knives in pairs, so they have the same weight, otherwise vibrations can
occur in the cutter.If knife profile is damaged, it should be re-grinded
again using professional sharpener. This service is usually available in
the nearby. If not, contact Wood-Mizer.
3.2.5 Variable speed motor manual
WARNING! Do not turn feed speed adjustment knob when the feed is
off or material is planing/moulding.
ASSEMBLY (IF VARIABLE SPEED MOTOR IS MOUNTED IN PLACE)
Mount feed motor on the last feed roller. Use the lock screw to secure the motor on the roller.
SETTING THE FEED SPEED
To set the feed speed use the knob located on the feed gear. To increase the speed turn the knob
right, to decrease - turn left.
MAINTENANCE
Fluid should be visible in the fluid inspection window. Fluid level should be checked when feed gear
is not working.
Fluid should be refilled when it is not visible in the inspection window. Use oil for automatic
gearboxes or compatible oil according to the table below.
The variator is filled with AGIP BLASIA 32 at the factory and does not normally require an oil change
during its life.
The worm gear oil does not normally need changing or topping up during the life of the gear.
See table 3-2. Recommended oil types.
AGIP BLASIA 32
SHELL A.T.F DEXRON
ESSO A.T.F DEXRON
MOBIL A.T.F 220
CASTROL DEXTRON II
BP AUTRAN DX
TABLE 3-2
