PLANER/MOULDER SPECIFICATIONS
Specifications of the planer/moulder
Specyfikacje EGdoc021023 5-4
5
See table 5-5. Specifications of the ECO planer/moulder motors for USA are listed below.
MP200EB7S
Top cutter motor
specifications
Side cutter motor
specifications
Feed motor specifi-
cations
Motor Type Electric Motor Electric Motor Electric Motor
Rated Voltage 3x230V 3x230V 3x230V
Rated revolutions 2860 r.p.m. 2860 r.p.m. 2820 r.p.m.
Rated power 4kW 6kW 0.37 kW
Wood-Mizer Part No. 537387 537385 533642
Wood-Mizer Reducer Part
No.
---- --- 533641
Wood-Mizer CVT Part No. ---- --- 533643
TABLE 5-4
MP200EC6U
Top cutter motor
specifications
Side cutter
motor specifi-
cations
Feed motor
specifications
Current
(FL)
Current
(LL)
SCCR
Motor Type Electric Motor Electric Motor Electric Motor 13 5,8 5kA
Rated Voltage 3x400-460V 3x400-460V 3x400-460V
Rated revolutions -- -- 1400 r.p.m.
Rated power 3kW 3kW 0.18 kW
Wood-Mizer Part No. 537386-UL 537385 532802-UL
Wood-Mizer Reducer Part
No.
---- --- --
TABLE 5-5
MP200EB6U
Top cutter motor
specifications
Side cutter
motor specifica-
tions
Feed motor
specifications
Current
(FL)
Current
(LL)
SCCR
Motor Type Electric Motor Electric Motor Electric Motor 25 10,2 5kA
Rated Voltage 3x230V 3x230V 3x230V
Rated revolutions -- -- 1400 r.p.m.
Rated power 3kW 3kW 0.18 kW
Wood-Mizer Part No. 537386-UL 537385 532802-UL
Wood-Mizer Reducer Part
No.
---- --- 533637
TABLE 5-5
