Setup
Side cutter setup
3
3-21 doc050624 Setup
See Figure 3-14.
REMOVING RIGHT OR LEFT SIDE CUTTER
WARNING! Wear gloves when working with knives in the machine.
Failure to follow this may result in serious injury or death.
See Figure 3-15. Location of the side cutters
FIG. 3-14
FIG. 3-15
Locking nut
Head
Spacers
Spacers (if needed)
Fixed side cutter head
Movable side cutter head
TOP VIEW
